Screw fasteners, standard and national standard German standard international standard corresponding table

Table of Contents

Screw fasteners, standard and national standard German standard international standard corresponding table:



Item German standard China Standard international standard
Self-drilling tapping screws DIN7504 GB15856.1-4
Plain washers DIN125-A GB97.1-85 ISO7089
Mediun washers DIN125-B GB97.2-85 ISO7090
Plain washers DIN126 ISO7091
Spring lock washers,tang ends DIN127-A GB7244
Spring lock washers,square ends DIN127-B GB93-87
Socket wrenches DIN911 ISO2936
Hexagon socket cap screws DIN912 GB70-85 ISO4762
Hexagon socket set screws with falt point DIN913 GB77-85 ISO4026
Hexagon socket set screws with cone point DIN914 GB78-85 ISO4027
Hexagon socket set screws with dog point DIN915 GB79-85 ISO4028
Hexagon socket set screws with cup point DIN916 GB80-85 ISO4029
Hexagon head screws DIN931 GB5782-86 ISO4014
Hexagon head screws DIN933 GB5783-86 ISO4017
Slotted countersund head screws DIN963 GB68-85 ISO2009
Slotted raised countersunk oval head screws DIN964 GB69-85 ISO2010
Cross recessed countersunk head screws DIN965 GB819-85 ISO7046
Cross recessed raised DIN966 GB820-85 ISO7047
Pan head tapping screws with cross recessed DIN7981 GB845-85 ISO7049
Countersunk flat head tapping screws with cross recessed DIN7982 GB846-85 ISO7050
Raised countersunk oval head tapping screws with cross DIN7983 GB847-86 ISO7051
Pan head tapping screws with slot DIN7971 GB5282-85 ISO1481
countersunk flat head tapping screws with slot DIN7972 GB5283-85 ISO1482
Raised sountersunk oval head tapping screws with slot DIN7973 GB5284-85 ISO1483
Hexagon tapping screws DIN7976 GB5285-85 ISO1479
Pan head screws with cross recessed DIN7985 GB818-85 ISO7045
Hexagon socket coutersunk head screws DIN7991 ISO10642
Prevailing rorque type hexagon nuts,heavy type,with nylon DIN982 GB812-88 ISO2982
Prevalling torque type hoxagon nuts,heavy type,with nylon DIN985 GB889.1-86 ISO7040
Preailling torque typedomed capnuts with nylon insert DIN986 GB6172.2-86 ISO10511
Hexagon full nuts DIN934 GB6170-86 ISO4032
Hexagon full nuts DIN934 GB6171-86 ISO8673
Hexagon thin nuts DIN936 GB6172.1-86 ISO4035
Hexagon thin nuts DIN439 GB6172-86 ISO4035
Slotted raised csk head wood screws DIN95 GB101
Slotted round head wood screws DIN96 GB99
Slotted countersunk head wood screws DIN97 GB100
Single coil spring lock washers DIN128-A GB7245-87
Curved spring washers DIN137-A
Wave spring washers DIN137-B GB955
T-head blots with square neck DIN186 GB37-88
T-head bolts with double nip DIN188
Taper pins with threaded end DIN258 ISO8737
T-head bolts DIN261
Wing nuts America form DIN315AF
Wing nuts germany form DIN315DF GB62-88
Wing screws America form DIN316AF
Wing screws germany form DIN317DF
Ball knobs DIN319
Slotted capstan screws DIN404 GB832-88
Slotted set srews with full dog point DIN417 GB75-85 ISO7435
Slotted set srews with chamfered end DIN427 GB73-85 ISO2342
Pip nuts with thread DIN431 GB808-88
External tap DIN432 GB856-88
Washers for cheese head screws DIN433 GB848-95 ISO7092
Square taper washers for DIN434 GB852-88
Square taper washers for DIN435 GB852-88
Square washers DIN436
Slotted set with cup point DIN438 GB74-85 ISO7436
Hexagon thin nuts DIN439 GB6173-86 ISO8675
Rounds washers for wood constructions DIN440 ISO7094
Sealing caps,push-in type DIN443
Eye bolts form B DIN444 GB798-88
Internal tab washers DIN462
Washers with two taps DIN463 GB855-88
Knurled thumb screws with collar DIN464 GB834-88
Slotted knurled thumb screws with collar DIN465
Knurled thumb nuts with collar DIN466 GB806-88
Knurled thumb thin nuts DIN467 GB807-88
Sealing washers DIN470
Retaining rings for shafts(external),circlips DIN471 GB893-86
Retaining rings for bores(internal),circlips DIN472 GB893.86
Square head bolts with collar DIN478
Square head bolts with half dog point DIN479
Square head bolts with collar,half dog point DIN480
T-slot nuts DIN508 ISO299
Single end studs DIN525
Masonry bolts DIN529 GB799-88
Slotted round nuts DIN546 GB817-76
Round nuts with drilled holes in one face DIN547 GB815-88
Slotted set screws with flat point DIN551 GB73-85 ISO4776
Slotted set screws with cone point DIN553 GB71-85 ISO7434
Hexagon nuts DIN555 ISO4034
Square nuts DIN557 GB39-88
Hexagon screws DIN558 ISO4018
Hexagon set screws with full dog point DIN561
Square nuts without bevel DIN562
Hexgon head wood screw DIN571 GB102-86
Lifting eye bolts DIN580 GB825-76 ISO3266
Lifting eye nuts DIN582
Hexagon blots DIN601 ISO4016
Mushroom head square neck bolts(carriage bolts) DIN603 GB14-88 ISO8677
Flat countersunk nib bolts DIN604
Flat countersunk long squareneck bolts DIN605
Cup head nib bolts DIN607
Flat countersunk short square neck bolts DIN608
Hexagon fitted bolts,long thread DIN609
Hexagon fitted bolts short thread DIN610
Knurled thumb screws thin type DIN653 GB835-88
Round head rivets DIN660 GB867-86 ISO1051
Contersunk head rivets DIN661 GB869-86 ISO1051
Raised contersunk head rivets DIN662 ISO1051
Mushroom head rivets DIN674 ISO1051
Adjusting rings,heavy range(shafting collars) DIN703
Adjusting rings,light range(shafting collars) DIN705 GB816-88
Wire rope clips DIN741
T-slot screws DIN787 ISO299
Studs-metal(end=2d) DIN835 GB900-88
Hexagon socket pipe plugs,conical thread DIN906
Thread DIN908
Thread DIN909
Hexagon head screw plugs,cyl.thread DIN910
Hexagon cap nuts DIN917
Slotted short cheese head screws DIN920
Slotted large cheese head screws DIN921 GB838-88
Slotted pan head screw with shoulder DIN923 GB830-88
Slotted shoulder screws DIN927
Square weld nuts DIN928 GB/T13680-92
Hexagon weld nuts DIN929 GB/T13681-92
Hexagon nuts type-1 DIN970
Hexagon nuts type-2 DIN971
Hexagon nuts with fine thread DIN972
Hexagon slotted and castle nuts DIN935 GB6178-86 ISO7035
Hexagon thin slotted and caslte nuts DIN937 GB6181-86 ISO7038
Studs metal(end=1d) DIN938 GB897-88
Studs metal(end=1.25d) DIN939 GB898-88
Studs metal(end=1.5d) DIN940
Hexagon head bolts,metric fine pitch thread DIN960 GB5785-86 ISO8765
Hexagon head bolts,metric fine pitch thread DIN961 GB8786-86 ISO8676
Additional shapes and versions for bolts DIN962
Threaded rods(studdings) DIN975 GB6176-86 ISO8674
Threaded pins(stud bolts) DIN976 GB15389-94
Hexagon thin slotted and castle nuts DIN979
Prevaillng rorque type hexagon nuts,all metal nuts DIN980
Locknuts DIN981 GB6184-86 ISO7199
Shim rings DIN988
Washers for timber connectors DIN1052
Round plain head nails DIN1151
Plain washers for clevis pins(A 型 ) DIN1440 ISO8738
Plain washers for clevis pins DIN1441
Clevis pins with head DIN1444 ISO2341
Grooved pins,taper grooved DIN1471 GB/T13829.2 ISO8744
Grooved pins,taper grooved half length DIN1472 GB/T13829.2 ISO8745
Grooved pins,parallel grooved full length DIN1473 ISO8100%
Grooved pins,reverve grooved half length DIN1474 ISO8741
Grooved pins,center grooved DIN1475 ISO8742
Grooved pins with round head DIN1476 ISO8746
Grooved pins with countersunk head DIN1477 ISO8747
Turnuckles(center parts),made out of hexagon bar DIN1479
Turnuckles with eye bolt and hook bolt DIN1480
Spring pins,heavy type DIN1481 GB879-86 ISO8752
Hexagon domed cap nuts DIN1587 GB802-88
Slotted round nuts for hook spammer DIN1804
Round nuts with set holes DIN1816
Disc springs DIN2093
Hose clamps DIN3017
Lubricating nipples,button head DIN3404
Shackles for conduilts DIN3567
Stirrup bolts(U-bolts) DIN3570
Spherical washers,conical seats DIN6319 GB849-88
Parallel pins DIN6325 ISO8734
Hexagon nuts,1.5d DIN6330 GB56-88
Hexagon nuts,1.5d with collar DIN6331 GB6177-86
Hexagon nuts,3d DIN6334
External teeth lock washers DIN6797-A GB862.1-87
Internal teeth lock washers DIN6797-I GB861.1-87
External teeth serrated lock washers DIN6798-A GB862.2-87
Internal teeth serrated lock washers DIN6798-I GB861.2-87
Retaining rings for shafts(E-rings),circlips DIN6799 GB896-76
Parallel keys(form A) DIN6885 ISO773/2491
Woodruff keys DIN6888 ISO3912
Thimbles DIN6899
Screws and washers assemblies DIN6900
Tapping screws and washer assemblies DIN6901 GB9074.1-17
Hexagon cocket head cap screws with hole,low head DIN6912 GB9074.18-23
Hexagon head bolts with large head DIN6914
Hexagon nuts with large wideth across flat DIN6915
Round washers for friction grip bolts DIN6916
Spuare taper washers for friction grip bolts on T- DIN6917
Hexagon flange nuts DIN6923 GB6187-86 ISO4161
Prevailing torque type hexagon nuts,all metallic nuts DIN6925 GB6185.1-2000 ISO7042
Spring pins,light type DIN7346 ISO13337
Washers for bolts with heavy type spring pinss DIN7349
Thread forming screws for ISO-metric thread DIN7500
Thread cutting screws DIN7513
Thread cutting screws cross recess DIN7516
Tee nuts with pronge DIN7965
Hexagon head fitted bolts for steel structures DIN7968 GB1228/1229/1230
Spring lock washers for screws with cylindrical heads DIN7980 ISO8738
Hexagon socket head cap screws with,reduced head DIN7984
Washers for steel structures DIN7989 GB1230-84
Hexagon head bolts for steel structures DIN7990 GB1229-84
Roundwire snap rings for shafts DIN7993 GB895.2-86
Cross recessed raised countersunk head wood screws DIN7995 GB952-86
Cross recessed round head wood screws DIN7996 GB950-86
Cross recessed countersunk head wood screws DIN7997 GB951-86
Ciol inserts,coarse,fine thread,silf locking DIN8140
Washers,outside diameter appro.3d DIN9021 GB96-85 ISO7093
sping cotter for a bolt DIN11024
Belting bolts(elevator bolts) DIN13257
Dry wall screws DIN18182
Lifting nuts(eye nuts) DIN28129 GB63-88
Tab washer for slotted round nuts DIN70952
Taper pins DIN1 GB117 ISO2339
Parallel pins DIN7 GB119-86 ISO2339
Slotted cheese head screws DIN84 GB65-85 ISO1207
Slotted pan head screws DIN85 GB67-85 ISO1580
Tab washers DIN93 GB854
Split cooter pins DIN94 GB91 ISO1234
